Product Overview:
This model is an itermittent motion and hole plate type full automatic capsule filling equipment. It adopts optimization design for meeting the characteristics of Chinese medicine and the requirement of GMP ,it has the characteristics of compact mechanism,small volume,lower noise ,precision flling dosage,multi-function,stable running etc.It can finish the following motion at the same time;capsule feeding,capsule separating,powder flling,capsule rejecting,capsule locking,finished capsule discharge and die hole cleaning etc.It is the ideal hard capsule fillig equipment for pharmaceutical and health food industry.
HMI for model C HMI for model H
Note: Model H has the following characteristics
1：Control system be provide with OPC Server.
2：Control system be realized with FDA 21CFR Part 11 e-signature e-recording.
3：Control system be provide with Industrial Ethernet Interface be connected with OPC Client.
4：High-capacity HD can be record message, meet CGMP and FDA.
5：Developed based on the ltalian ESA system.
Technical Parameters：
Model | NJP-700C/H | ||
| Flling Dosage Form | Powder, Granule, Pellet | ||
| Capsule Size | Capsule size 00”-5”and safety capsule A-E | ||
| Max. Output | 42,000 Capsules/Hour | ||
| Power Supply | 380V 50Hz 1 .92kW 220V 60Hz 1.87kW | ||
| Noise | ≤75dBA | ||
| Vacuum Degree | -0.02~-0.06 MPa | ||
| Compressed Airclean segment) | Air consumption：3m³/h Pressure：0.3~0 4MPa | ||
| Number of Holes | 5 hole | ||
| Dimensions | 810X945X 1930mm | ||
| Weight | 800kg | ||
Dimensional Drawing:
