Product Overview:
This model is an iteritnt motion and hole plate type full automatic capsule filling equipment. It adopts optmization design for meeting the characteristics of Chinese medicine and the requirement of GMP,it has the characteristics of compact mechanism,small volume,lower noise,precision fling dosage,multi-function,stable running etc.It can finish the following motion at the same time;capsule feeding,capsule separating,powder fling,capsule rejecting,capsule locking,finished capsule discharge and die hole cleaning etc.It is the ideal hard capsule filling equipment for pharmaceutical and health food industry.
HMI for model C HMI for model H
Note: Model H has the following characteristics
1：Control system be provide with OPC Server.
2：Control system be realized with FDA 21CFR Part 11 e-signature e-recording.
3：Control system be provide with Industrial Ethernet Interface be connected with OPC Client.
4：High-capacity HD can be record message, meet CGMP and FDA.
5：Developed based on the ltalian ESA system.
Technical Parameters：
MODEL | NJP-1250C/H | |
Filling Dosage Form | Powder, Granule or Pellet | |
Capsule Size | Capsule size 00"-5" and safety capsule A-E | |
Max.Output | 75000Capsules / Hour | |
Number of Holes | 9 hole | |
Power Supply | 380V 50Hz 2.67kw 220V 50Hz 2.57kw | |
Noise | ≤75dBA | |
Vacuum Degree | -0.02～-0.06 MPa | |
Compressed Air(clean segment) | Air consumption：3m3/h Pressure：0.3~0.4MPa | |
Dimensions | 870×1020×2000mm | |
Weight | 900kg | |
Dimensional Drawing:
